12 x 7 ft Flat Deck Hydraulic Tipping Trailer ATM 3.5 tonne (3,500kg)

This is without doubt the King of Tipper Trailers. This flat deck trailer is equipped with fully removable sides, front and rear gates and also has a 600 high removable cage which is also able to be removed one section at a time for added convenience. For the easy loading of machinery, recreational vehicles or any other mobile equipment, extra heavy duty hot dipped galvanised ramps included and housed in under trailer deck.

The trailer floor has been upgraded to an extra heavy duty 4mm thick checker plate making it one of the toughest and most durable hydraulic tipping trailers available. Great for farmers, tradesmen, machinery operators or anyone looking for a high-capacity versatile tipping flat deck trailer.

  • Hot Dipped Galvanised (Rust Free) – ATM 3500KG
  • 1900MM long Draw Bar
  • Solid 60mm Axles Rated at 2400KG each
  • Removable 450mm High Sides and 900mm High Cage (Total Height: 1350mm)
  • 4-Stage Hydraulic Tipping Ram with 3500KG Loading Capacity
  • 2 x Extra Heavy Duty Loading Ramps Housed under Trailer Deck
  • 15 inch Brand New Sunraysia Rims and Light Truck Tyres
  • 4 x Wheel 12 inch Electric Brakes with emergency Break-a-way system
  • Massively Reinforced Under Floor with Extra Beams
  • Fully Welded Heavy Duty Chassis
  • 9 Leaf Heavy Duty Springs with Rocker Roller Suspension
  • Fully Removable Sides plus front rear gates
  • Sides and Rear fitted with Tie-down Rails
  • 10 inch HD Swing up Jockey Wheel Included
  • LED Tail Lights
  • ADR Standard Heavy Duty Chain & Load Rated Shackles
  • Flat 7 Pin Plug

All Wide Bay Trailers come with a One Year Factory Backed Warranty for absolute peace of mind when you purchase.

Model: 12 x 7 ft Tandem Flat Deck Trailer
ATM: 3500kg
Chassis: 100mm x 50mm x 5mm
Trailer Deck Size: 3600mm x 2100mm (x 450mm with sides on)
Drawbar: 2000mm, 100mm x 50mm x 3mm
Body: Drop in Headboard, Drop down/Remove able sides & Rear Panel
Finish: Hot Dipped Galvanized
Side: Removable 450mm High Sides and 600mm High Cage – 1100mm Headboard
Flooring: 4mm Checker plate
Cage: 600mm cage included only included
Jockey Wheel: 10″ Heavy Duty Swing Up
Wheel: New 195R15C 6 STUD Wheels and Tyres
Spare Wheel and Holder: Included
Brake: 12″ Electric Drum Brake x 4

Solid 60mm Axles Rated at 2400KG each, HD Dexter Bearings

Coupling: 50mm Australia Standard
Lights: LED
Lights Plug: Flat 7 Pin Plug
Spring: 9 Leaf Heavy Duty Rocker Roller Spring
Safety Chain: 2 x 12mm
Ladder Racks: Optional
Warranty: 12 months Limited Warranty
