10 x 5 ft Tandem Hydraulic Tipper Trailer with Ramps ATM 3500kg

Multi stage Hydraulic Ram offers a Maximum of nearly 85 Degree Tipping angle. Provides smooths tilting and enough tipping angle to make any unloading job a breeze. Includes 400mm sides and 600mm galvanized Cage. 100 AMP Deep Cycle Battery and 2 Heavy Duty slide out Ramps, Spare Wheel and Six Months Rego.

This is an outstanding NEW MODEL heavy-duty, robust tipper trailer with incredible versatility. 3.5tonne ATM with a load capacity of around 2.6tonne.

Great for moving those big loads and would suit farmers, machinery operators, tradespeople or anyone needing to move and deliver those bulky heavy loads with ultimate ease.

Great for loading machinery of all shapes and sizes with versatile loading ramps able to be set in many positions across the rear channels at the back of the trailer.

  • DECK SIZE: 3000 x 1525mm  (10 x 5 ft)
  • Dual Structural chassis supper strong and flexible upper 70mm & lower 100mm
  • Under body extra bracing for trade use long lasting construction
  • 2 Heavy duty Slide out Ramps
  • Rust Free. ATM 3500KG
  • Fully Welded Heavy Duty Body and Chassis. Rust Free. Great for Tradesman all in one trailer now
  • Spare Tyre post option
  • Fling Open Tail Gate, able to leave tailgate on when using ramps and tipping
  • Heavy Duty Lock down latches
  • Full Length Tie Down Rails
  • Heavy Duty Dexter Bearings for trade use
  • Each Axle rated at 2000kg each
  • Dexter heavy duty Bearings
  • Comes with 12″ Electric Brakes
  • Quality Breakaway Unit fitted
  • LED lights with Marker Lights on the sides. ADRs Complied.
  • 50mm 3.5t Quick Release Coupling
  • 1900mm Long Draw Bar. With 100mm x 50mm x 5mm with Extra under bracing reinforced draw-bar.
  • 3500KG Tow hitch brake/handbrake
  • 50mm Solid Axles. Rocker Roller Suspension with Heavy Duty 9 Leaf Springs
  • 6  stud 15 inch Landcruiser
  • Brand new  195 R15c White Sunraysia Light Truck Tyres
  • Comes with wind Up 10″ Heavy Duty Jockey Wheel
  • MULTI  Stages Hydraulic ram
  • Recessed equipment box in A Frame allows full drop down of front tailgate.

All Wide Bay Trailers come with a One Year Factory Backed Warranty for absolute peace of mind when you purchase.

Model: 10 x 5 ft Tandem Hydraulic Tipper Box Trailer
ATM: 3500KG
Chassis: 100mm x 50mm x 5mm
Trailer Deck Size: 3000mm x 1525mm (x 400mm high sides)
Drawbar: 1900mm, 100mm x 50mm x 6mm
Body: Checker plate 400mm High sides
Finish: Hot Dipped Galvanized
Side: 400mm Removable front and Rear Tail Gates
Flooring: 2.5mm Checkerplate
Cage: 600mm Included (900mm Optional)
Jockey Wheel: 10″ Heavy Duty Swing Up
Wheel: New 195R15C 6 STUD Wheels and Tyres
Spare Wheel and Holder: Included
Brake: 12″ Electric Drum Brake x 4
Axle: Dual Axle, 50mm Solid Axles, HD Dexter Bearings
Coupling: 50mm Australia Standard
Lights: LED
Lights Plug: Flat 7 Pin Plug
Spring: 9 Leaf Heavy Duty Rocker Roller Spring
Safety Chain: 2 x 12mm
Ladder Racks: Optional
Warranty: 12 months Limited Warranty
SKU 10x5HT
Brand Wide Bay Trailers
